Vertical Sliding Table

• Precision Sliding Tables are meant for accurate boring, drilling grinding and milling operations.
• Grey iron casting properly machined and grinded process provides accuracy well within 0.01mm/100mm tolerance.
• Toughened lead screw having acme threads running smoothly in phosphorus Bronze Nut.
• Dovetail slides have adjustable steel ribs for smooth running and adjustment.
• Precision ACME feed screw is running in a hot stamped phosphor Bronze Nut thrust color for smooth operation and minimum back lash.
• Designed to fit on any Lathe, will enable you to mill slots, Key ways, grooves, flats, squares, also drilling at any angle.
• The T-Slots are machined from Solid.
• Equipped with two axis positioning.
• Dovetailed slides have adjustable steel gibs to compensate for wear.
• The surface table can swivel all round and 0° is marked to show the angular movement.
• Base have bolt slots for machine mounting.
