Description
Dimension in mm
Item Code No. | Type | D | D | L | L1 | G | G1 |
---|---|---|---|---|---|---|---|
ABM-IMT-7390 | SK 30 / FMC 22 x 045 | 22 | 40 | 45 | 19 | M 12 | M 10 |
ABM-IMT-7391 | SK 40 / FMC 22 x 045 | 22 | 40 | 45 | 19 | M 16 | M 10 |
ABM-IMT-7392 | SK 40 / FMC 22 x 090 | 22 | 40 | 90 | 19 | M 16 | M 10 |
ABM-IMT-7393 | SK 40 / FMC 27 x 060 | 27 | 48 | 60 | 21 | M 16 | M 12 |
ABM-IMT-7394 | SK 40 / FMC 27 x 090 | 27 | 48 | 90 | 21 | M 16 | M 12 |
ABM-IMT-7395 | SK 40 / FMC 32 x 060 | 32 | 58 | 60 | 24 | M 16 | M 16 |
ABM-IMT-7396 | SK 40 / FMC 32 x 075 | 32 | 58 | 75 | 24 | M 16 | M 20 |
ABM-IMT-7397 | SK 40 / FMC 40 x 060 | 40 | 76 | 60 | 27 | M 16 | M 16 |
ABM-IMT-7398 | SK 50 / FMC 22 x 060 | 22 | 40 | 60 | 19 | M 24 | M 10 |
ABM-IMT-7399 | SK 50 / FMC 22 x 105 | 22 | 40 | 105 | 19 | M 24 | M 10 |
ABM-IMT-7400 | SK 50 / FMC 27 x 045 | 27 | 48 | 45 | 21 | M 24 | M 12 |
ABM-IMT-7401 | SK 50 / FMC 27 x 090 | 27 | 48 | 90 | 21 | M 24 | M 12 |
ABM-IMT-7402 | SK 50 / FMC 27 x 150 | 27 | 48 | 150 | 21 | M 24 | M 12 |
ABM-IMT-7403 | SK 50 / FMC 32 x 045 | 32 | 58 | 45 | 24 | M 24 | M 16 |
ABM-IMT-7404 | SK 50 / FMC 32 x 075 | 32 | 58 | 75 | 24 | M 24 | M 16 |
ABM-IMT-7405 | SK 50 / FMC 32 x 105 | 32 | 58 | 105 | 24 | M 24 | M 16 |
ABM-IMT-7406 | SK 50 / FMC 40 x 060 | 40 | 76 | 60 | 27 | M 24 | M 20 |
