Description
Table Diameter 5″ (125/ 127 mm).
Overall Height in vertical position 90 mm.
Worm Gear Ratio 1:72 which means that the 1 handle rotation shall turn the table by 5º.
T Stot width (Top of the table) : 12 mm.
Table Graduated 360º, Vernier Scale is calibrated to 10 seconds.
Center Bore of the Table 2 MT.
Can be clamped in Horizontal as well as vertical.
| Item Code No. | Type | Table Dia. | T Slot Width mm | Gear Ratio |
|---|---|---|---|---|
| ABM-VC-2640 | H&V | 5" / 125mm | 12mm | 72:1 |
| ABM-VC-2641 | Rotary Table + Clamping Kit | |||
| ABM-VC-2642 | Rotary Table + Dividing Plate Set | |||
| ABM-VC-2643 | Rotary Table + Dividing Plate Set + Tailstock | |||
* H&V Means Horizontal & Vertical
