Description
- Rigid Material Vise Body of Ductile Iron.
- It is Fitted with Thrust Bearing for Smooth Movement.
- This Tilt Lock Vices can with stand heavy jobs.
- Top & Bottom of vice bed, bottom & both sides of jaws & all jaw mounting surfaces are precision ground.
- By reversing the jaw plates the jaws are raised & can be fitted to both ends of the fixed jaws & the moveable jaws.
- The four different positions of jaw plates pair are available for more gripping area.
- Coolant through on vise body and swivel base.
- Chip clearance holes, no dead pockets.
- Swivel handle allows the screw head revolved on machine table.
- The vice can be disassembled and repaired by regrinding.
- Supplied with Stopper for Fast Production.
| Item Code No | ABM-VC-11017 |
|---|---|
| Width of Jaws mm | 70 |
| Length Overall mm | 540 |
| Height Overall mm | 110 |
| Tenon Slot Size mm | 12 |
| Weight Approx Kg. | 22 Kg. |
