Description
• Drill bit can cut in only axial direction, a milling bit can cut generally in all the directions though some cannot cut axially.
• End Mill cutters cut material on both the periphery and end simultaneously creating stress since the tool is held only at the spindle.
• Milling bit are used in Milling applications such as profile milling, tracer milling, face milling ,plunging.
• With Centre Cutting and without Centre Cutting.
• Threaded End Mills Also available.
• COBALT STEEL are suitable for use on tougher materials and all heavy duty applications that require an increased depth of cut. Addition of cobalt gives optimum hardness and toughness thus improving the cutting performance.
• HIGH SPEED STEEL show exceptional results on mild steel, alloy steels and tool steel and are superior finishing tools useful in production processes.
(a) STUB LENGTH L=2″ (As per ANSI B94.19)
(b) REGULAR LENGTH L=2-1/4″ (As per ANSI B94.19)
(c) LONG LENGTH (As per ANSI B94.19)
(a) STUB LENGTH L=2″ (As per ANSI B94.19)
| Item Code No. 2 Flutes | Item Code No. 4 Flutes | Size | Length of Cut |
|---|---|---|---|
| ABM-CT-14090 | ABM-CT-14100 | 3/32" | 9/64" |
| ABM-CT-14091 | ABM-CT-14101 | 7/64" | 5/32" |
| ABM-CT-14092 | ABM-CT-14102 | 1/8" | 3/16" |
| ABM-CT-14093 | ABM-CT-14103 | 9/64" | 7/32" |
| ABM-CT-14094 | ABM-CT-14104 | 5/32" | 15/64" |
| ABM-CT-14095 | ABM-CT-14105 | 11/64" | 1/4" |
| ABM-CT-14096 | ABM-CT-14106 | 3/16" | 9/32" |
(b) REGULAR LENGTH L=2-1/4″ (As per ANSI B94.19)
| Item Code No. 2 Flutes | Item Code No. 4 Flutes | Size | Length of Cut |
|---|---|---|---|
| ABM-CT-14120 | ABM-CT-14130 | 3/32" | 9/32" |
| ABM-CT-14121 | ABM-CT-14131 | 7/64" | 21/64" |
| ABM-CT-14122 | ABM-CT-14132 | 1/8" | 3/8" |
| ABM-CT-14123 | ABM-CT-14133 | 9/64" | 13/32" |
| ABM-CT-14124 | ABM-CT-14134 | 5/32" | 7/16" |
| ABM-CT-14125 | ABM-CT-14135 | 11/64" | 1/2" |
| ABM-CT-14126 | ABM-CT-14136 | 3/16" | 1/2" |
(c) LONG LENGTH (As per ANSI B94.19)
| Item Code No. 2 Flutes | Item Code No. 4 Flutes | Size | Length Below Shank | Length of Cut | Overall Length |
|---|---|---|---|---|---|
| ABM-CT-14150 | ABM-CT-14160 | 3/32" | 1/2" | 9/32" | 2-5/8" |
| ABM-CT-14151 | ABM-CT-14161 | 7/64" | 1/2" | 9/32" | 2-5/8" |
| ABM-CT-14152 | ABM-CT-14162 | 1/8" | 3/4" | 3/4" | 3-1/8" |
| ABM-CT-14153 | ABM-CT-14163 | 9/64" | 3/4" | 3/4" | 3-1/8" |
| ABM-CT-14154 | ABM-CT-14164 | 5/32" | 7/8" | 7/8" | 3-1/4" |
| ABM-CT-14155 | ABM-CT-14165 | 11/64" | 7/8" | 7/8" | 3-1/4" |
| ABM-CT-14156 | ABM-CT-14166 | 3/16" | 1" | 1" | 3-3/8" |
