CNC lathes use this type of center almost exclusively and they may be used for general machining operations as well. Spring-loaded live centers are designed to compensate for center variations, without damage to the work piece or center tip. This assures the operator of uniform constant tension while machining.

Loading...

Description

Live Center / Revolving Center – High Precision with Standard Nozzle

•  This center can be used on all CNC lathes, has a point angle of   60 degrees with double angular contact bearing, thrust bearing  and needle roller bearing at the end of point in the shank.
  Available in two types with a carbide point and with a tool  steel point.
  Concentricity within 0.005 mm.
  Bearings are protected by a neoprene seal for longer life.
  Consists of Triple Bearings.



Item Code No.
Carbide Point
Item Code No.
Tool Steel Point
Morse
Taper
Max RPMWork Pc Weight
ABM-IMT-4350ABM-IMT-4354MT23500300
ABM-IMT-4351ABM-IMT-4355MT33500400
ABM-IMT-4352ABM-IMT-4356MT43500550
ABM-IMT-4353ABM-IMT-4357MT52500750
