Description
• Precision Live Centers having small bodies having an extended point useful on all CNC lathes, has a point angle of 60 degrees.
• Fitted with multiple roller bearings and thrust bearing at the end of the points in the shank for Long Life and smooth operation.
• Concentricity within 0.008 mm for MT1, MT2 & MT3.
• Concentricity within 0.01 mm for MT6.
• Bearings are protected by a neoprene seal for longer life.
| Item Code No. Carbide Point | Item Code No. Tool Steel Point | Taper | Max RPM | Work Pc Weight |
|---|---|---|---|---|
| ABM-IMT-4380 | ABM-IMT-4384 | MT2 | 4000 | 150 |
| ABM-IMT-4381 | ABM-IMT-4385 | MT3 | 4000 | 300 |
| ABM-IMT-4382 | ABM-IMT-4386 | MT4 | 4000 | 600 |
| ABM-IMT-4383 | ABM-IMT-4387 | MT5 | 3000 | 1200 |
