CNC lathes use this type of center almost exclusively and they may be used for general machining operations as well. Spring-loaded live centers are designed to compensate for center variations, without damage to the work piece or center tip. This assures the operator of uniform constant tension while machining.

Loading...

Description

•  Precision Live Centers having small bodies useful on all  CNC lathes, has a point angle of 60 degrees.
•  Fitted with multiple roller bearings and thrust bearing at the end of the points in the shank.
•  Concentricity within 0.005 mm for MT1, MT2 & MT3.
•  Concentricity within 0.01 mm for MT6.
•  Bearings are protected by a neoprene seal for longer life.
•  Available in two types with Carbide Points or Tool Steel Points.



Item Code No.
Carbide Point
Item Code No.
Tool Steel Point
TaperMax RPMWork Pc Weight
ABM-IMT-4370ABM-IMT-4374MT24000200
ABM-IMT-4371ABM-IMT-4375MT34000400
ABM-IMT-4372ABM-IMT-4376MT44000800
ABM-IMT-4373ABM-IMT-4377MT530001600
