Face Mill Arbor BT MAS 403 / FMB

Description

Dimension in mm

Item Code No.	Type	D	D1	L	L1	G	G1
ABM-IMT-7000	BT 30 / FMB 16 x 045	16	40	45	17	M 12	M 8
ABM-IMT-7001	BT 30 / FMB 22 x 047	22	45	47	19	M 12	M 10
ABM-IMT-7002	BT 30 / FMB 27 x 050	27	63	50	21	M 12	M 12
ABM-IMT-7003	BT 40 / FMB 22 x 055	22	45	55	19	M 16	M 10
ABM-IMT-7004	BT 40 / FMB 27 x 060	27	63	60	21	M 16	M 12
ABM-IMT-7005	BT 40 / FMB 27 x 090	27	63	90	21	M 16	M 12
ABM-IMT-7006	BT 40 / FMB 32 x 060	32	78	60	24	M 16	M 16
ABM-IMT-7007	BT 40 / FMB 32 x 090	32	78	90	24	M 16	M 16
ABM-IMT-7008	BT 40 / FMB 40 x 060	40	90	60	27	M 16	M 20
ABM-IMT-7009	BT 40 / FMB 40 x 075	40	90	75	27	M 16	M 20
ABM-IMT-7010	BT 50 / FMB 27 x 045	27	63	45	21	M 24	M 12
ABM-IMT-7011	BT 50 / FMB 27 x 090	27	63	90	21	M 24	M 12
ABM-IMT-7012	BT 50 / FMB 27 x 150	27	63	150	21	M 24	M 12
ABM-IMT-7013	BT 50 / FMB 32 x 060	32	78	60	24	M 24	M 16
ABM-IMT-7014	BT 50 / FMB 32 x 090	32	78	90	24	M 24	M 16
ABM-IMT-7015	BT 50 / FMB 40 x 060	40	90	60	27	M 24	M 20
ABM-IMT-7016	BT 50 / FMB 40 x 075	40	90	75	27	M 24	M 20
ABM-IMT-7017	BT 50 / FMB 40 x 105	40	90	105	27	M 24	M 20
