Description
Dimension in mm
Item Code No. | Type | D | D1 | L | L1 | L2 | G | G1 |
---|---|---|---|---|---|---|---|---|
ABM-IMT-7280 | SK 30 / SL 6 x 065 | 6 | 25 | 65 | 17.5 | -- | M 12 | M 6 |
ABM-IMT-7281 | SK 30 / SL 8 x 065 | 8 | 28 | 65 | 17.5 | -- | M 12 | M 8 |
ABM-IMT-7282 | SK 30 / SL 10 x 065 | 10 | 35 | 65 | 19.5 | -- | M 12 | M 10 |
ABM-IMT-7283 | SK 30 / SL 12 x 065 | 12 | 42 | 65 | 22 | -- | M 12 | M 12 |
ABM-IMT-7284 | SK 30 / SL 14 x 065 | 14 | 44 | 65 | 22 | -- | M 12 | M 12 |
ABM-IMT-7285 | SK 30 / SL 16 x 065 | 16 | 48 | 65 | 23.5 | -- | M 12 | M 14 |
ABM-IMT-7286 | SK 30 / SL 18 x 065 | 18 | 50 | 65 | 23.5 | -- | M 12 | M 14 |
ABM-IMT-7287 | SK 30 / SL 20 x 090 | 20 | 52 | 90 | 24.5 | -- | M 12 | M 16 |
ABM-IMT-7288 | SK 30 / SL 25 x 090 | 25 | 65 | 90 | 23.5 | 25 | M 12 | M 18 X 2 |
ABM-IMT-7289 | SK 40 / SL 6 x 065 | 6 | 25 | 65 | 17.5 | -- | M 16 | M 6 |
ABM-IMT-7290 | SK 40 / SL 8 x 065 | 8 | 28 | 65 | 17.5 | -- | M 16 | M 8 |
ABM-IMT-7291 | SK 40 / SL 10 x 065 | 10 | 35 | 65 | 19.5 | -- | M 16 | M 10 |
ABM-IMT-7292 | SK 40 / SL 12 x 065 | 12 | 42 | 65 | 22 | -- | M 16 | M 12 |
ABM-IMT-7293 | SK 40 / SL 14 x 065 | 14 | 44 | 65 | 22 | -- | M 16 | M 12 |
ABM-IMT-7294 | SK 50 / SL 16 x 065 | 16 | 48 | 65 | 23.5 | -- | M 16 | M 14 |
ABM-IMT-7295 | SK 50 / SL 18 x 065 | 18 | 50 | 65 | 23.5 | -- | M 16 | M 14 |
ABM-IMT-7296 | SK 50 / SL 20 x 090 | 20 | 52 | 90 | 24.5 | -- | M 16 | M 16 |
ABM-IMT-7297 | SK 50 / SLA25 x 090 | 25 | 65 | 90 | 24.5 | 25 | M 16 | M 18 x 2 |
ABM-IMT-7298 | SK 50 / SLA32 x 090 | 32 | 72 | 90 | 23.5 | 28 | M 16 | M 20 x 2 |
ABM-IMT-7299 | SK 50 / SL 6 x 075 | 6 | 25 | 75 | 17.5 | -- | M 24 | M 6 |
ABM-IMT-7300 | SK 50 / SL 8 x 075 | 8 | 28 | 75 | 17.5 | -- | M 24 | M 8 |
ABM-IMT-7301 | SK 50 / SL 10 x 075 | 10 | 35 | 75 | 19.5 | -- | -- | M 10 |
ABM-IMT-7302 | SK 50 / SL 12 x 075 | 12 | 42 | 75 | 22 | -- | M 24 | M 12 |
ABM-IMT-7303 | SK 50 / SL 14 x 075 | 14 | 44 | 75 | 22 | -- | M 24 | M 12 |
ABM-IMT-7304 | SK 50 / SL 16 x 075 | 16 | 48 | 75 | 23.5 | -- | M 24 | M 14 |
ABM-IMT-7305 | SK 50 / SL 18 x 075 | 18 | 50 | 75 | 23.5 | -- | M 24 | M 14 |
ABM-IMT-7306 | SK 50 / SL 20 x 105 | 20 | 52 | 105 | 24.5 | -- | M 24 | M 16 |
ABM-IMT-7307 | SK 50 / SLA 25 x 105 | 25 | 65 | 105 | 23.5 | 25 | M 24 | M 18 x 2 |
ABM-IMT-7308 | SK 50 / SLA 32 x 105 | 32 | 72 | 105 | 23.5 | 28 | M 24 | M 20 x 2 |
ABM-IMT-7309 | SK 50 / SLA 40 x 105 | 40 | 84 | 105 | 23.5 | 34 | M 24 | M 24 x 2 |
