Drill Point Gauge – With Hook Ruler

This gage was designed specifically for use in drill grinding. It provides a quick, accurate way for determining the correct drill point angle of 59º and the correct length of drill lips necessary for clean-cut drilling at maximum feeds and speeds.

The head is beveled to 59 degree (the correct drill point angle)
It is also graduated in 1/32″ along the 59 degree face for measuring the drill lips which should be of equal lengths
The hook rule has accurate, machine-divided graduations in 1/8″, 1/16″, quick-reading 1/32″ and 64″
Hook is adjustable and can be shortened or extended on either side of the rule, and may also be removed if desired
This gage was designed specifically for use in drill grinding, It provides a quick, accurate way for determining the correct drill point angle of 59 degree and the correct length of drill lips necessary for clean-cut drilling at maximum feeds and speeds
These rugged steel measures feature a satin chrome finish, sliding heads and adjustable and removable hook rules.

• For properly grinding 59° drill points and for measuring drill tips.
• Rule and slide are made of steel with satin chrome finish .
• Rigid rule is calibrated in 8ths, 16ths,32nds and 64ths.
• End clip / Hook  is adjustable and removable.
• Slide is calibrated in 32nds and 64ths.
