Boring heads are designed for precision production boring on machining centers, boring mills, transfer machines and high speed milling machines. Their fully enclosed, compact and rugged design allows reliable operation, even under extreme cutting conditions. A small boring bar is inserted into one of the holes. The head can be shifted left or right with fine gradation by a screw, adjusting the diameter of the circle that the cutting tip swings through, thus controlling the hole size.

Loading...

Description

•  Integrated Shank for maximum rigidity.
•  Hardened  and  Ground  Body.
•  This Boring Head has a single piece rugged construction for a smooth and chatterless operations
•  Hardened slide with a black oxide finish.
•  Available in R8 and straight shanks.

Boring Heads have three major components:
1.   Boring head body
2.  Bar holder/insert holder
3.  Dial screw

Item Code No.Head
Dia.
Overall
Length
Draw Bar
Thread
Max. Off
Set
Center Distance
B/W Holes
Cross Vertical
Hole Size
Min
Bore
Max
Bore
Shank
ABM-IMT-479050 mm165 mm7/16 x 20 UNF20 mm16 mm12 mm3/4”5”R8
ABM-IMT-47912-1/2”7-3/16”7/16 x 20 UNF3/4”5/8”1/2”3/4”5”R8
