Acme Standard Screw Thread Gage is a standard for grinding and setting tools when cutting Acme threads, which have the same depth as square threads but the sides of the threads are at an inclination of 14-1/2 Deg (29 Deg included angle)

Loading...

Description

Acme Screw Thread Gauge
Acme Screw Thread Gage

• Made of Polished Stainless Steel
• Clearly Etched Graduation
• Used for Gaging Thread Profiles 47-1/2° British Association, 14-1/2 Acme 60° American
• Acme Standard Screw Thread Gage is a standard for grinding and setting tools when cutting Acme threads, which have the same depth as square threads but the sides of the threads are at an inclination of 14-1/2 Deg (29 Deg included angle).
• This form of thread is used extensively and has in many instances replaced the square thread in machine construction.
• The advantages of the Acme thread is its strength and the ease by which it can be cut compared with square threads.
• The angles and edges of this gage are hardened, ground and carefully tested
• The angle on the thread cutting tool is checked on the large precision-ground V at the end of the gage.
• Used for grinding and setting acme thread cutting tools.
• Identical depth for all slots in the gauge.

ITEM CODE NO.    ABM-EPT-9760
